LS Water Manifold for Remote Mount electric Water Pump

Compact and Efficient Cooling Solution for Your LS Engine

Our new ICT Billet LS Water Manifold allows you to run a remote electric water pump for a cleaner, more efficient cooling setup, saving valuable horsepower at high rpm. This new design allows us to build accessory brackets that are compatible with this water manifold, not found anywhere else on the market. We know that retaining your power steering and alternator and sometimes A/C (low mount passenger side) is a real challenge!

• Compact design allows for easy remote water pump integration
• Four -16 ORB ports are designed for maximum coolant flow for optimal cooling performance
• Two 1/8" NPT ports for convenient steam port connections
• One-piece billet aluminum construction eliminates potential leaks and simplifies installation
• Made in Wichita, Kansas from aerospace grade, USA produced, billet aluminum
• Includes 1 water manifold, OE style gaskets, mounting hardware, and -16 ORB Orings
• if using this water manifold, with a motor plate AND ICT# BKT-LS01-E1 accessory bracket, then the motor plate should be cut back so it is not under the water manifold, IF using the 16AN ports on the driver side behind the bracket.

Helpful Links

• Replacement -216 oring
